Forklift Mast Chain

Forklift Mast Chain - Leaf Chains have different functions and are regulated by ANSI. They are intended for low-speed pulling, for tension linkage and forklift masts, and as balancers between counterweight and head in several machine tools. Leaf chains are at times likewise called Balance Chains.

Construction and Features

Made of a simple link plate and pin construction, steel leaf chains is identified by a number which refers to the lacing of the links and the pitch. The chains have particular features like high tensile strength for each section area, that allows the design of smaller machines. There are B- and A+ type chains in this series and both the BL6 and AL6 Series have the same pitch as RS60. Finally, these chains cannot be powered using sprockets.

Selection and Handling

Comparably, in roller chains, all of the link plates maintain higher fatigue resistance due to the compressive stress of press fits, while in leaf chains, only two outer plates are press fit. The tensile strength of leaf chains is high and the utmost allowable tension is low. If handling leaf chains it is vital to confer with the manufacturer's manual in order to guarantee the safety factor is outlined and utilize safety measures always. It is a great idea to exercise extreme caution and utilize extra safety guards in functions where the consequences of chain failure are serious.

Using a lot more plates in the lacing causes the higher tensile strength. Since this does not enhance the utmost allowable tension directly, the number of plates used could be restricted. The chains need regular lubrication as the pins link directly on the plates, producing a really high bearing pressure. Using a SAE 30 or 40 machine oil is often advised for the majority of applications. If the chain is cycled over one thousand times daily or if the chain speed is more than 30m per minute, it will wear very quick, even with continual lubrication. Therefore, in either of these situations utilizing RS Roller Chains will be more suitable.

The AL-type of chains must only be used under particular situations like if wear is really not a huge issue, if there are no shock loads, the number of cycles does not exceed one hundred a day. The BL-type would be better suited under different conditions.

If a chain using a lower safety factor is chosen then the stress load in parts will become higher. If chains are utilized with corrosive elements, then they may become fatigued and break rather easily. Doing regular maintenance is vital when operating under these kinds of conditions.

The type of end link of the chain, whether it is an outer link or inner link, determines the shape of the clevis. Clevis connectors or Clevis pins are made by manufacturers but usually, the user supplies the clevis. A wrongly made clevis could lessen the working life of the chain. The strands must be finished to length by the manufacturer. Refer to the ANSI standard or contact the maker.
